MCAC-VTSM-2015-09 R410A All DC Inverter V4+S Series 60Hz
Specifications & Performances 79
10. Accessories
10.1 Standard accessories
No
Name
Quantity
Purpose
1
Installation manual of outdoor unit
1
/
2
Outdoor unit owner’s manual
1
Be sure to deliver it to the customer
3
Indoor unit owner’s manual
1
Be sure to deliver it to the customer
4
Toggling flathead screw
1
For toggling of indoor and outdoor units
5
Gauge point subassembly
1
For purpose of air tight test units
6
90° mouthing elbow
1
For connecting pipes
7
Seal plug
8
For pipe cleaning
8
Connective pipe accessory
1
Connect to the side of liquid pipe
9
Bolt bage
1
Stone for service
10
Switching pipe (Air side)
1 (the qty. of 12,14HP are 2)
Connect to the air pipe side, use when it is needed
10.2 Optional accessories
Branch joint of outdoor & indoor unit
Optional
accessories
Model name
Packing Size
in.(mm)
Net/gross
Weight (Ibs.(kg))
Function
Branch joint of
outdoor side
FQZHW-02N1D
10-1/16×6×7-5/16 (255×150×185)
3.3/2.6 (1.5/1.2)
Distribute the
refrigerant to
indoor units and
balance the
resistance
between each
outdoor unit.
FQZHW-03N1D
13-9/16×6-5/16×11-1/4 (345×160×285)
7.5/5.3 (3.4/2.4)
FQZHW-04N1D
18-11/16×6-1/2×11-7/8 (475×165×300)
10.6/7.9 (4.8/3.6)
Branch joint of
indoor side
FQZHN-01D
11-7/16×4-1/8×4 (290×105×100)
0.9/0.7 (0.4/0.3)
FQZHN-02D
11-7/16×4-1/8×4 (290×105×100)
1.3/0.9 (0.6/0.4)
FQZHN-03D
12-3/16×5-1/8×5 (310×130×125)
2.0/1.3 (0.9/0.6)
FQZHN-04D
13-3/4×6-5/8×7-1/8 (350×170×180)
3.3/2.4 (1.5/1.1)
FQZHN-05D
14-3/8×7-11/16×8-1/2 (365×195×215)
4.2/3.1 (1.9/1.4)
10.3 Other optional accessories
Optional accessories
Model name
Function
Outdoor controller
MD-CCM02/E
Monitor the outdoor operating parameter
Three phase electricity power
protector
DPA51CM44
or
HWUA/DPB71CM48
To stop the air-conditioner running in case of bad power
supply such as Phase Error, Over-voltage, Under-voltage
lose, phase lost and phase sequence inverse. Thus to protect
the equipment.
Digital ammeter (WHM)
DTS634/DT636
Electricity Charge monitor
