88 Installation
Example B
Unit: in.( mm)
AA≥300(11-3/4)
BB≥250(9-7/8)
CC≤8000(314-15/16)
θ
θ≤15°
725
(28-9/16)
Air outlet louver dimension (optional)
90
(3-9/16)
100(3-15/16)
B
1290(50-25/32) 1210(47-5/8)
Radius
Support
C
A
Remove the two
iron filters firstly
12 ST3.9 self-threading screws
10
(3/8)
10
(3/8)
12-Φ3.2(Φ1/8)
393
(15-15/32)
765
(30-1/8)
1250(49-7/32)
411
(16-3/16)
411
(16-3/16)
213
(8.-3/8)
