4. Reverse the above procedure to install. And check out all connectors connects well.
Removal and replacement
1. Take out sump assembly. (see sump assembly
removal and installation)
2. Remove heater elements assembly. (see heater
elements assembly removal and replacement)
3. Take out gasket of heater elements support assembly.
4. Reverse the above procedure to install. And check out all connectors connects well.
Removal and replacement
1. Take out sump assembly. (see sump assembly
removal and installation)
2. Turn the sump assembly, and remove all screws for
fixing thermal resistor.
3. Reverse the above procedure to install. And check out all connectors connects well.
Removal and replacement
1. Take out sump assembly. (see sump assembly removal and
installation)
2. Pull out check plate holder assembly.
Check plate
Thermal resistor
Heater elements support assembly
Nu
