ACCESSORY CONNECTIONS
External Speaker (Sold Separately)
If you plan to use an external speaker, choose a speaker with an impedance of 8Ω. The
external speaker jack accepts a 3�5mm (1/8”) mono (2-conductor) plug�
External speaker utilizes a double port BTL, please take care when connecting a
speaker to this port. Do not allow the speaker to make contact with a ground, as it
could damage the speaker.
The image on page 11 shows the incorrect connecting method.
6� When routing the antenna cable inside the vehicle, keep the cable away from noise
sources, such as the ignition system, gauges, etc�
7� Exercise care to prevent cable damage� Make use of existing gaskets, grommets and
weather stripping to protect the cable along its route�
