page 27
midlandusa.com
Signaling Combination Setup
This function can improve the level of blocking of irrelevant signals
1� Enter the CHAN MENU, choose the No�6 function
2� Press the [PUSH] button, the menu value in the LCD turns to green
3� Turn the channel knob to choose the desired setting
SQ:You can hear the call when receiving a matching carrrier
CDT:You can hear the call when receiving a matching carrier and CTCSS or DCS
signaling
TONE: You can hear the call when receiving matching carrier + optional signaling�
C&T: You can hear the call when receiving matching carrier + CTCSS/DCS + optional
signaling
C/T: You can hear the call when receiving any matching carrier or CTCSS/DCS or
optional signaling
4� Press the [PUSH] button or the [P3] button to store the setting and exit
Bandwidth Selection
Select the desired bandwidth in accordance with dierent local conditions and laws
1� Enter the CHAN MENU list, choose the No�7 function
2� Press the [PUSH] button, the menu value in the LCD turns to green
3� Turn the channel knob to choose the desired setting
WID: band width is 25k(Wide band)
MID: band width is 20k(Middle band)
NAR: band width is 12�5k(Narrow band)
4� Press the [PUSH] button or the [P3] button to store the setting and exit
Frequency Reverse
With this function on, the transceiver will be able to communicate with a transceiver in
the same network without the use of a repeater�
1� Enter the CHAN MENU list, choose the No�8 function
2� Press the [PUSH] button, the menu value in the LCD turns to green
3� Turn the channel knob to choose the desired setting
ON: Turn on reverse function
OFF: Turn o reverse function
4� Press the [PUSH] button or the [P3] to store the setting and exit
Talk Around
1� Enter the CHAN MENU list, choose the No�9 function
2� Press the [PUSH] button, the menu value in the LCD turns to green
