Model MXT115
Microphone Controls
1. Channel Up
2. Channel Down
3. Automatic Noise Cancelling
Rear Panel Connections
1. ANT Jack - SO-239 UHF connector for ext ernal antenna (included)
2. EXT SPKR Jack - 3.5mm Audio connector for optional ext ernal speaker
(purchased separately) (see Using an External Speaker for
VSHFL¿FDWLRQV
3. 13.8V DC Cable - 2-wire DC connector for 12V DC nominal input power
connection
EXT SP
ANT
1
2
3
ANC
