Model SP-8 &10
optIonAl lIGHt pACkAGe sCHemAtIC sp-2065 rev-A
NO REQ DESCRIPTION PART NUMBER
1 1 ADAPTER, TEE, 9/16-18 FJIC x 9/16-18 MJIC x 9/16-18 MJIC 203102-6-6S
2 1 ADAPTER, STRAIGHT, 9/16-18 FJIC x 7/16-20 MJIC 221501-6-4S
3 1 ADAPTER, STRAIGHT, 1/8 FNPT x 7/16-20 FJIC SWIVEL 2242-2-4S
4 4 HEX HD CAP SCREW 3/8-16 UNC x 1 HCS-3/8-16-1.00
5 4 HEX NUT, 3/8-16 UNC HXN-3/8-16
6 4 LOCK WASHER, 3/8 LKW-3/8
7 1 PRESSURE SWITCH, SPDT, 30-600 PSI, 1/8MNPT M18120
8 1 RELAY, 40 AMP (VF4) M4066
9 1 SWITCH, TOGGLE, (32NT91-1) M6427
10 1 SWITCH, TOGGLE, (31NT91-1) M6430
11 1 SWITCH, TOGGLE, (32NT91-2) M6431
12 1 CIRCUIT BREAKER, 25 AMP M6455
13 1 ELECTRONIC TAIL LIGHT CONVERTER M6493
14 1 RESISTOR, 6 OHM 50 WATT M6495
15 1 SNOW PLOW HEADLIGHT / TURN SIGNAL KIT M6517
16 2 DOUBLE FACE PARK & TURN SIGNAL LIGHT W/ SIDE MARKER M6518
17 1 TRAILER HARNESS, SPLIT (LIGHTS) M6519
18 1 FLASHER,TURN SIGNAL M6520
19 3 PUSH ON TERMINAL, INSULATED, FEMALE- WIRE RANGE-16/14, SPADE SIZE - 1/4 POF-16/14-0.25
20 2 RING TERMINAL, INSULATED - WIRE RANGE-16/14 STUD SIZE - # 10 RT-16/14-10
21 4 RING TERMINAL, INSULATED - WIRE RANGE-22/16 STUD SIZE #10 RT-22/16-10
22 1 STROBE LIGHT INSTALLATION SP-2067
23 2 MOUNTING BRACKET, RESISTOR / CONVERTER SP-2069
24 2 WEATHER PACK CONNECTING KIT, 2 PIN FEMALE 16-14 GA. WIRE SP-2145-40
25 5 WEATHER PACK CONNECTING KIT, 2 PIN MALE 16-14 GA. WIRE SP-2145-41
26 3 WEATHER PACK CONNECTING KIT, 3 PIN MALE 16-14 GA. WIRE SP-2145-43
27 1 LIGHT PACKAGE HARNESS KIT SP-2145-KIT
28 1 HEADLIGHT BRACKET, R/S SP-263-1
29 1 HEADLIGHT BRACKET, L/S SP-263-2
30 2 TURN SIGNAL MOUNT SP-264 REV-B
31 20” WIRE, SINGLE CONDUCTOR, STRANDED 14 GA, RED WIR-1402
32 10” WIRE, SINGLE CONDUCTOR, STRANDED 18 GA, RED WIR-1802
33 10” WIRE, SINGLE CONDUCTOR, STRANDED 18 GA, BLACK WIR-1810
