Model SP-8 &10
NO REQ DESCRIPTION PART
NUMBER
1 1 PUMP, TANDEM M9045SF
2 1 PUMP, HYDRAULIC GEAR, SP-8 & SP-10 M1230
3 1 O-RING, BUNA N, #151, 3” ID x 3/32
WIDTH
M17123
4 1 MANIFOLD ASSY, W/(6) SOLENOID
VALVES (SP)
M18111
5 3 CAVITY PLUG (MANIFOLD SP) M18113
6 1 ACCUMULATOR, OIL-AIR, 30 CU IN W/
ADAPTER FITTING
M18118
7 1 PRESSURE SWITCH, 1200 PSI RISING
(SP MANIFOLD BRAKE**2 WIRE)
M18114
8 1 PRESSURE SWITCH, 2000 PSI RISING
(SP MANIFOLD BRAKE-3 WIRE)
M18116
9 1 VALVE, DIRECTIONAL CONTROL, W/
BODY SP-6, SP-8 & SP-10
M18115
10 1 MANIFOLD, RETURN, 4 PORT M17074
11 2 VALVE, COUNTERBALANCE M14078
12 2 BRAKE PEDAL ASSY, 0-1200 PSI
MODULATING (SP-8 , -10 ,-12)
M14145
13 1 LOAD SHUTTLE VALVE SP-8 M14147
14 1 FILTER ASSEMBLY, HIGH PRESS. M6051
15 1 FILTER HEAD, LOW PRESSURE (SP
PUMP MNT.)
M6049A
16 1 FILTER ELEMENT, HIGH PRESSURE, 6”
(SP-PUMP MNT.)
M3059A
17 2 STRAINER, SUCTION, 1-1/2 MNPT x 1
FNPT
M6035
18 1 TANK, HYDRAULIC, 30 GAL M18002
19 REF FILL CAP (FURNISHED WITH TANK) M13068
20 1 MAGNETIC PLUG, 1/2 MNPT M6053
21 1 VIEW GAGE - HYD TANK SA-337-12
22 1 VALVE, RELIEF SW-642-86
23 1 VALVE, HOT OIL SHUTTLE M18075
* 25 3 ADAPTER, 45° ELBOW, 1-1/16-12 FJIC
SWIVEL x 1-1/16-12 MJIC
2070-12-12S
* 26 3 ADAPTER, TEE, BULKHEAD, 9/16-18
MJIC
203008-6-6S
* 27 5 ADAPTER, 90° ELBOW, 1-5/16-12 MORB
x 1-1/16-12 MJIC
2062-16-12S
* 28 1 ADAPTER, STRAIGHT, 1-1/16-12 MORB x
1-1/16-12 MJIC
202702-12-12S
* 29 1 ADAPTER, TEE, 9/16-18 MORB x 9/16-18
MJIC x 9/16-18 MJIC
203005-6-6S
* 30 3 ADAPTER, CAP NUT, 9/16-18 FJIC 210292-6S
* 31 1 ADAPTER, STRAIGHT, 1-5/8-12 MORB x
1-5/8-12 MORB (BRENNAN)
3474-20-20-
NWO
* 32 1 ADAPTER, STRAIGHT, 1-5/8-12 MORB x
1-1/4 HOSE BARB (BRENNAN)
4604-20-20-O
* 33 1 ADAPTER, STRAIGHT, 1-1/16-12 MORB x
3/4 HOSE BARB (BRENNAN)
4604-12-12-O
* 34 1 ADAPTER, STRAIGHT, 7/8-14 MORB x
3/4-16 MJIC
202702-10-8S
* 35 3 ADAPTER, 90° ELBOW, 3/4 MNPT x 3/4-
16 MJIC
2024-12-8S
* 36 4 ADAPTER, STRAIGHT, 1 MNPT x 1-1/16-
12 MJIC
2021-16-12S
* 37 1 ADAPTER, REDUCER, 1MNPT x 3/4FNPT 2081-16-12S
* 38 1 ADAPTER, STRAIGHT, 3/4 MNPT x 3/4
HOSE BARB (BRENNAN)
4404-12-12
NO REQ DESCRIPTION PART
NUMBER
* 39 1 ADAPTER, STRAIGHT, 1 MNPT x 1-1/4
HOSE BARB (BRENNAN)
4404-20-16
* 40 1 ADAPTER, PLUG, HEX HD, 1 1/4 MNPT 2082-20S
* 41 1 ADAPTER, REDUCER, 1-1/4 MNPT x 3/4
FNPT
2081-20-12S
* 42 1 ADAPTER, 90° ELBOW, 3/4 MNPT x
1-1/16-12 MJIC
2024-12-12S
* 43 2 ADAPTER, 90° ELBOW, 3/4 MNPT x
9/16-18 MJIC
2024-12-6S
* 44 1 ADAPTER, STRAIGHT, 3/4 MNPT x 9/16-
18 MJIC
2021-12-6S
* 45 2 ADAPTER, 90° ELBOW, 3/8 MNPT x
9/16-18 MJIC
2024-6-6S
* 46 3 ADAPTER, PLUG, HEX HD, 3/8 MNPT 2082-6S
* 47 2 ADAPTER, STRAIGHT, 3/4-16 MORB x
3/4-16 MJIC
202702-8-8S
* 48 3 ADAPTER, STRAIGHT, 3/4-16 MORB x
9/16-18 MJIC
202702-8-6S
* 49 16 ADAPTER, STRAIGHT, 9/16-18 MORB x
9/16-18 MJIC
202702-6-6S
* 50 3 ADAPTER, PLUG, HEX HD 3/4-16 MORB 900598-8S
* 51 8 ADAPTER, PLUG, HEX HD 9/16-18
MORB
900598-6S
* 52 5 ADAPTER, 90° ELBOW, 9/16-18 MORB x
9/16-18 MJIC
2062-6-6S
* 53 2 SPLIT FLANGE, CODE 62, 3/4” (2)
HALVES,W/ HDWR & O-RING
FF595-12-449
* 54 1 ADAPTER, 90° ELBOW, 7/8-14 MORB x
9/16-18 MJIC
2062-10-6S
* 55 3 ADAPTER, STRAIGHT, 9/16-18 MJIC x M
14-1.5 METRIC MALE
GG108-
NP-06-14
* 56 2 ADAPTER, 90° ELBOW, 3/4-16 MJIC x M
18-1.5 METRIC MALE
GG308-
NP-08-18
* 57 2 ADAPTER, STRAIGHT, 3/4-16 FJIC x
9/16-18 MJIC
221501-8-6S
* 58 2 ADAPTER, TEE, 9/16-18 FJIC x 9/16-18
MJIC x 9/16-18 MJIC
203102-6-6S
* 59 2 ADAPTER, TEE, 1-1/16-12 MJIC x 1-1/16-
12 MJIC x 1-1/16-12 FJIC
203101-12-12S
* 60 1 ADAPTER, TEE 9/16-18 MJIC x 3/4-16
MORB x 9/16-18 MJIC (BRENNAN)
6804-06-08-06-
NWO
* 61 1 ADAPTER, RESTRICTOR, 9/16-18 FJIC x
9/16-18 MJIC W/ .094 ORIFICE
FF1981-094-
0606
* 62 10 ADAPTER, STRAIGHT, BULKHEAD,
9/16-18 MJIC
2041-6-6S
* 63 3 ADAPTER, 90° ELBOW, 3/4-16 MORB x
9/16-18 MJIC
2062-8-6S
* 65 3 ADAPTER, STRAIGHT, 3/4-16 MORB x
3/8 MNPT (BRENNAN)
6401-08-06-O
* 66 5 ADAPTER, STRAIGHT, 3/8 MNPT x 9/16-
18 MJIC
2021-6-6S
* 67 2 ADAPTER, PLUG, HEX HD, 1/4 MNPT 2082-4S
* 68 2 ADAPTER, TEE, 9/16-18 MJIC x 9/16-18
MJIC x 3/8 MNPT
2030-6-6S
* 69 1 ADAPTER, STRAIGHT, 1-5/16-12 MORB x
1-1/16-12 MJIC
202702-16-12S
* 70 1 ADAPTER, 90° ELBOW , 1-1/16-12 FJIC
SWIVEL x 1-1/16-12 MJIC
FF5163-12-12S
71 1 DIODE/RELAY BOX ASSY, SP-8 &-10 SP-2161
* 74 2 ADAPTER, STRAIGHT, 3/4-16 MORB x
1-1/16-12 MJIC
202702-8-12S
HydrAulIC InstAllAtIon sp-8, sp-10 (sInGle sIded), sp-769 rev-C
