Model SP-8 & 10
Note:
1. Left side blade and column assembly is available in dual sided conguration only.
2. When setting up left side blade and column assembly for paving, dismount following components from right side blade
assembly (See Section 4.2.1 for components)
Push Tube Assembly (View A-A in Section 4.2.1), Item 53, 54 and 55.
Assemble these components on left side as the mirror image of right side.
NO. REQ DESCRIPTION PART NUMBER
1 1 COLUMN (FIXED) SP-421
2 1 COLUMN (MOVEABLE) SP-426
3 1 CYL RING SP-431
4 1 KEY (AT CYL RING) SP-434
5 1 BLADE PIVOT, CURVED BLADE ASS’Y. SP-435
6 1 BLADE SECTION (1 FT) SP-441
7 2 BLADE SECTION (2 FT) SP-444
8 1 EDGER (INNER) SP-447
9 1 EDGER MOUNT (EDGER-IN) SP-451
10 1 HINGE PIN (EDGER-IN) SP-453
11 2 GUIDE (EDGER-IN) (5-1/2 x 11) SP-455
12 1 MTG BRACKET (SLOPE TUBE)- L/H SP-591
13 1 SLOPE TUBE (OUT) SP-460
14 1 SLOPE TUBE (MID) SP-462
15 1 SLOPE TUBE (IN) SP-464
16 1 OUTER EDGER ASSEMBLY, SP-8/-10 BLADE SP-590
17 1 SLEEVE (BLADE PIVOT) SP-497
18 1 MTG BRACKET (PUSH TUBE) SP-498
19 2 CYLINDER, HYD., TIE ROD, 2-1/2” x 18” M1013
20 2 PIN, HITCH W/ LYNCH PIN 3/4 x 4-3/4 M11006
21 6 LUBE FITTING, STRAIGHT (SERRATED) 1743-8
22 2 HEX HD CAP SCREW 5/16-18 UNC x 5/8 HCS-5/16-18-0.63
23 8 HEX HD CAP SCREW 5/16-18 UNC x 7/8 HCS-5/16-18-0.88
24 10 LOCK WASHER, 5/16 LKW-5/16
25 4 HEX HD CAP SCREW 1/2-13 UNC x 1-1/2 HCS-1/2-13-1.50
26 11 HEX HD CAP SCREW 1/2-13 UNC x 1-3/4 HCS-1/2-13-1.75
27 4 HEX HD CAP SCREW 1/2-13 UNC x 2-1/4 HCS-1/2-13-2.25
28 2 HEX HD CAP SCREW 1/2-13 UNC x 2-1/2 HCS-1/2-13-2.50
29 1 SOCKET HD CAP SCREW 1/2-13 UNC x 1-3/4 KCS-1/2-13-1.75
30 24 HEX NUT, 1/2-13 UNC HXN-1/2-13
31 24 LOCK WASHER, 1/2 LKW-1/2
32 5 HEX HD CAP SCREW 5/8-11 UNC x 5-1/2 HCS-5/8-11-5.50
33 5 HEX NUT, 5/8-11 UNC HXN-5/8-11
34 5 LOCK WASHER, 5/8 LKW-5/8
35 1 HEX HD CAP SCREW 1-8 UNC x 6-1/2 HCS-1-8-6.50
36 1 HEX NUT, 1-8 UNC HXN-1-8
37 1 LOCK WASHER, 1 LKW-1
38 1 MTG BRACKET (EDGER-OUT) SP-483
39 1 HINGE PIN (EDGER-OUT) SP-486
40 8 HAIRPIN, COTTER, ZINC PLATED M11013
41 1 BALL HITCH, 2 DIA, ZINC-PLATED M11005
