Model SP-8 & 10
NO REQ DESCRIPTION PART NUMBER
1 1 ENGINE JD, TIER III, SP-8** M6364
2 REF BATTERY M18101
3 REF BACK UP ALARM M18100
4 REF FUEL CAP (SUPPLIED WITH TANK) M13068
5 1 FUEL TANK, 50 GAL M18001
6 6 ENGINE MOUNT WASHER M5006A
7 6 ENGINE MOUNT M5030
8 6 ENGINE MOUNT WASHER M5006
9 60” FUEL LINE, 3/8 ID H192
10 1 SENDING UNIT M18020
11 42” PETROLEUM HOSE 2” ID, 150 PSI 9M100
12 1 ELBOW, 45°, 2” FNPT M9088
13 1 ADAPTER - 2”HOSE BARB x 2 MNPT M20029
14 2 HOSE CLAMP SAE NO. 36 HS-36
15 1 FUEL FILLER NECK WELDMENT SP-149
16 1 BATTERY CABLE, NEG, 24” LG. (BLACK) SP-585
17 1 BATTERY CABLE, POS, 54”LG. (RED) SP-583
18 1 BATTERY CABLE, NEG, 45” LG. (BLACK) SP-584
19 22” FUEL LINE, 3/8 ID H192
20 75” FUEL LINE, 3/8 ID H192
21 55” FUEL LINE, 5/16 ID 9M0050
22 1 FUEL FILTER/SEPARATOR T-1184-04
23 1 MUFFLER GUARD (SP-8 & 10) SP-2124
24 1 SHELL SP-416
* 25 1 HOSE END, BRASS, 9/16-18 FJIC SWIVEL x 1/4 HOSE, PUSH-LOK 30682-6-4
* 26 4 HOSE END, BRASS, 9/16-18 FJIC SWIVEL x 3/8 HOSE, PUSH-LOK 30682-6-6
* 27 1 HOSE END, BRASS, 3/8 FNPT X 3/8 HOSE, PUSH-LOK 30282-6-6
* 28 1 ADAPTER, 90° ELBOW, 1/2 MNPT x 9/16-18 MJIC 2024-8-6S
* 29 2 ADAPTER, 90° ELBOW, 3/4-16 MORB x 9/16-18 MJIC 2062-8-6S
* 30 1 ADAPTER, 90° ELBOW, 1/8 MNPT x 9/16-18 MJIC 2024-2-6S
* 31 1 ADAPTER, 90° ELBOW, 3/8 MNPT x 9/16-18 MJIC 2024-6-6S
32 1 VENT, STEEL AND BRONZE FILTER M6356
33 4 HEX HD CAP SCREW 5/8-11 UNC x 2 HCS-5/8-11-2.00
34 6 HEX HD CAP SCREW 5/8-11 UNC x 3 HCS-5/8-11-3.00
35 4 FLAT WASHER, 5/8 FLW-5/8
36 10 LOCK WASHER, 5/8 LKW-5/8
37 10 HEX NUT, 5/8-11 UNC HXN-5/8-11
38 8 WASHER HD THREAD FORMING SCREW 3/8-16 UNC x 3/4 TFS-3/8-16-0.75
39 2 HEX HD CAP SCREW 5/16-18 UNC x 1-1/4 HCS-5/16-18-1.25
40 3 HEX HD CAP SCREW 5/16-18 UNC x 1 HCS-5/16-18-1.00
41 2 FLAT WASHER, 5/16 FLW-5/16
42 5 LOCK WASHER, 5/16 LKW-5/16
43 5 HEX NUT, 5/16-18 UNC HXN-5/16-18
44 6 HOSE CLAMP, MINIATURE SAE NO. 04 MH-04
* These Components are part of SP-315-FK Rev-E Fitting Kit.
** See John Deere Engine Manual supplied with the machine for more detail
