Page 9
midlandusa.com
Model MXT115
Operating Controls
1. LCD Display
2Q2ႇ9ROXPH
3. Microphone Jack
4. USB Charging Jack
5. Menu - Press to access menu
6. Weather - Press to access weather mode
7. Call /
Lock - Press to send a call signal, or long press to lock the
keypad
8.
Monitor / Scan - Press to enter scan mode, or long press to enter
monitor mode
Using an External Speaker
The MXT115 provides a rear-panel jack for connection of an optional
external speaker (purchased separately).
When selecting an external speaker, ensure the speaker has 8-ohm
impedance and is rated for 4.0 watts.
NOTE: When an external speaker is connected, the radio’s internal
speaker is automatically disabled.
CONTROLS AND INDICATORS
