Page 19
midlandusa.com
Model MXT115
When a transmission with the correct tone is received, the mute is
removed and the voice audio can be heard. When the transmission ends
the channel is muted again. Transmissions that do not have the correct
tone are not heard.
The MXT115 has 142 Privacy Codes (38 CTCSS codes and 104 DCS
codes), which can be applied to any channel. If desired, you can select
DGLႇHUHQW3ULYDF\&RGHIRUHDFKFKDQQHO6HHCTCSS Privacy Codes
Frequency Chart and DCS Privacy Codes Chart for lists of available
Privacy Codes.
IMPORTANT! To communicate between two radios, both radios must be
set to the same channel (see Selecting the Active Channel) and Privacy
Code selections.
To select a Privacy Code:
1. Press and release the Menu button to a place the radio in “Menu”
mode.
2. Use the Channel Up or Channel Down button to scroll through
the menu options until the LCD display shows Pt, then press the
Monitor/Scan / button.
3. Use the Channel Up or Channel Down button to selct the
privacy tone type you would like to use: for CTCSS or for DCS
4. 3UHVVWKH0RQLWRU6FDQEXWWRQWRFRQ¿UP\RXUVHOHFWLRQ
ƒ The (for CTCSS) or (for DCS) icon will show on the LCD
display, according to your selection
5. Use the Channel Up or Channel Down button to scroll forward or
backward through the available Privacy Codes until the desired Privacy
Code is shown on the LCD display.
NOTE: DCS Privacy Codes 100-104 are shown on the LCD display as
A0-A4.
NOTE: Selecting a Privacy Code of “oF” will disable the Privacy feature.
