Midtronics EXP-925 User Manual

EXP-925
Midtronics B.V. Hoofdveste 6 - 8 Houten NL
www.midtronics.com
25
Chapter 7: QC test
Jump Start Post
UNDER HOOD
4. Select the PLATFORM.
1  PLATFORM 1
2  PLATFORM 2
3  PLATFORM 3
Press the NEXT soft key to continue.
5. Select the CAR MODEL. Depending on the chosen plat-
form you will see dierent models, e.g.:
208 (A9)/ 2008 (A94)
OTHER
Press the NEXT soft key to continue.
6. Select the BATTERY RATING. Again, the options you get
here all depend on what you have chosen before.
640 A(EN)
Press NEXT to begin the battery test.
UNDER SEAT
4. Select the BATTERY RATING. The battery rating that
you can choose from depends on the battery location.
For example:
1  480 A(EN)
2  640 A(EN)
Press the NEXT soft key to continue.
5. Enter the MINIMUM VOLTAGE.
Press NEXT to begin the battery test.
TRUNK
4. Select the BATTERY RATING.
1  800 A(EN)
2  950 A(EN)
Press the NEXT soft key to continue.
5. Select the CAR MODEL. The models that you can choose
depend on the chosen BATTERY RATING.
407
C5
Press the NEXT soft key to continue.
6. Enter the VIN (950 A(EN) only).
Press NEXT to begin the battery test.
7. Enter the MINIMUM VOLTAGE.
Press NEXT to begin the battery test.
Battery Post
4. Select the BATTERY TYPE
1  REGULAR
2  AGM
3  GEL
Press the NEXT soft key to continue.
5. Select the RATING UNITS
1  EN
2  EN2
3  DIN
4  IEC
5  SAE
6  JIS
7  CCA
Press the NEXT soft key to continue.
6. Select the BATTERY RATING
Press the UP ( ) and DOWN ( ) ARROW keys to select
the rating. In case of a JIS battery type the part number.
7. Enter the MINIMUM VOLTAGE.
Press NEXT to begin the battery test.
