Chapter 12: Tester Internal Batteries
The Tester uses 6 AA, 1.5-volt batteries (alkaline
recommended) to allow testing of batteries down to 1 volt
and supply power while the menu is active. The analyzer can
test batteries down to 5.5 volts when the internal batteries
are not functioning.
Battery Power Indicator
The square in the upper left corner of the display indicates
the charge level of the battery pack. The square is black
when the battery pack is fully charged. It gradually changes
to white as the charge level declines. The Tester will display a
warning message when the batteries need replacing.
Full Powered
by test
battery
Decreasing Low
Power Level Indicator for AA Batteries
Replacing the Tester Batteries
1. Turn the Tester face down.
2. Press gently on the ridges above the arrow on the bat-
tery compartment cover.
3. Slide the cover in the direction of the arrow and remove
the cover.
4. Remove the discharged batteries.
5. Insert new batteries. Make sure the positive and nega-
tive terminals are positioned correctly.
6. Insert the door’s tabs into the slots on the analyzer and
slide the door closed, making sure the latch locks.
Chapter 12: Tester Internal Batteries
