Technical data
60
PWM514 machine data
Electrical connection
Supply voltage see data plate
Frequency see data plate
Total rated load see data plate
Current draw see data plate
Fuse rating see data plate
Heater rating see data plate
Installation dimensions
Casing width (without add-on components) 795 mm
Casing height (without add-on components) 1350 mm
Casing depth (without add-on components) 897 mm
Overall machine width 799 mm
Overall machine height 1352 mm
Overall machine depth 1010 mm
Minimum width of transport opening 805 mm
Minimum distance between wall and front of appliance 1395 mm
Minimum distance between wall and rear of appliance 400 mm
Weight and floor load
Net weight see installation plan
Maximum floor load during operation see installation plan
Emissions data
Sound pressure level emission in workplace in accordance with ENISO11204/11203 <70 dB(A) re 20 μPa
Sound power level EN ISO 9614-2 <80 dB (A)
Product safety
Product safety standard
AS/NZS 60335-1, AS/NZS 60335-2-7
EN 60335-1, EN 50571
Wi-Fi
Frequency band of the Wi-Fi module 2.400–2.4835GHz
Maximum transmission power of the Wi-Fi module <100mW
