Miele S 344i - Electric Brush Socket (S 254 I and S 255 I Only); Suction Hose with Integrated Wiring (S 2 Xx Only); S 254 I and S 255 I; S 270 I - S 276 I, S 280 I

Technical Information
52
S 2xx, S 3xx & S 4xx Canister Vacuums
3. When the brushes need changing, always change both at the same time.
The brush set always includes one brush with automatic worn-brush cut-
out.
5.21 Electric Brush Socket (S 254i and S 255i Only)
1. Unscrew the retaining screws under the socket.
2. Remove the cord cover.
5.22 Suction Hose with Integrated Wiring (S 2xx Only)
5.22.1 S 254i and S 255i
This has a built-in socket in the handle for installing the S 016 electric brush.
Figure 5-37: S 254i and S 255i Suction Hose with Integrated Wiring
5.22.2 S 270i - S 276i, S 280i
Wired hose with built-in socket in the handle for the S 016 electric brush.
Note:
2-wire connection cable.
