Installation and connection
78
Changing the door hinging
You can change the door hinging on
this tumble dryer yourself.
For safety reasons, the tumble
dryer must be disconnected from the
electricity supply before changing
the door hinging.
You will need:
– a Torx T20 and T30 screwdriver
– a flat head screwdriver or pointed
pliers
– the lock catch cover supplied
– the door hinge cover supplied
– a soft surface (e.g., a blanket)
Changing the hinging over
1. Remove the door from the tumble
dryer
Open the door.
Use a T30 Torx screwdriver to
unscrew the two screws on the base
plate of the door hinge .
The door cannot fall off.
Hold the door securely and pull it
forwards: to remove the door you will
need to pull the base plate of the
hinge with its 2 pins out of the dryer.
To avoid scratching the door, place it
outer side downwards on a soft
surface (e.g., a blanket).
2. Change over the door lock on the
dryer
Use a Torx T30 screwdriver to
unscrew the two screws on the door
lock .
Use the screwdriver to press the door
lock upwards.
The door lock will spring out of its
position and can then be removed.
