SECTION 3 − DEFINITIONS
3-1. Additional Safety Symbols And Definitions
Warning! Watch Out! There are possible hazards as shown by the symbols.
Safe1 2012−05
Never use generator inside a home or garage, even if doors and win-
dows are open.
Safe87 2012−07
Only use generator outside and far away from windows, doors, and
vents.
Safe88 2012−07
3-2. Miscellaneous Symbol Definitions
A
Amperage
V
Voltage
Negative
Positive
Alternating
Current (AC)
Protective Earth
(Ground)
Air Filter
Engine Start
Engine RPM
Circuit Breaker
Supplementary
Protector
Direct Current
(DC)
Fuel
Idle (Slow)
Engine Choke
T emperature
Battery (Engine)
Read Operator’s
Manual
Engine Oil
Engine
Engine Stop
Run (Fast)
Hertz
Output
On
Percent
U
0
Rated No−Load
Voltage (OCV)
U
2
Conventional
Load Voltage
I
2
242a Rated
Current
X
Duty Cycle
Shielded Metal
Arc Welding
(SMAW)
Gas Metal Arc
Welding (GMAW)
Gas Tungsten Arc
Welding (GTAW) /
Tungsten Inert
Gas (TIG)
Welding
Flux Cored Arc
Welding (FCAW)
Tungsten Inert
Gas (TIG) Lift Arc
Remote
Single Phase
Alternator
Arc Control
USB
Push Button
Air Carbon Arc
Cutting (CAC-A)
Rotating Knob
And Push Button
Arc Control
Read Instructions
Pulse
Done
Voltage Sense Input
