OM-243 347 Page 12
?
Do not weld on drums or any closed containers.
Safe64 2012−06
Do not remove or paint over (cover) the label.
Safe20 2012−05
Drive rolls can injure fingers.
Safe32 2012−05
Welding wire and drive parts are at welding voltage during operation − keep hands and metal objects away.
Safe33 2012−05
Wear hat and safety glasses. Use ear protection and button shirt
collar. Use welding helmet with correct shade of filter. Wear complete
body protection.
Safe66 2012−06
Become trained and read the instructions before working on the
machine or welding.
Safe65 2012−06
3-2. Miscellaneous Symbols And Definitions
. Some symbols are found only on CE products.
Output
A
Amperes
V
Volts
Direct Current
(DC)
X
Duty Cycle Wire Feed Percent
IP
Degree Of
Protection
Input
Cold Jog (Inch)
Towards
Workpiece
Purge By Gas
Hz
Hertz
Constant Current Circuit Breaker Constant Voltage Set Up
Trigger Hold Off Trigger Hold On
I
2
Rated Welding
Current
Increase
I
1
Primary Current Sequence Program Process
Wire Type Gas Type
Variable
Inductance
Time
Arc Control Trigger Control Preflow Time Postflow Time
Single Phase Three Phase Line Connection Gas Input
Read Instructions
U
1
Primary Voltage
U
2
Conventional Load
Voltage
To Next Page
