6-6. Accessing User Setup Menu: AC And DC Stick
1 Menu Button
Press and hold Menu button for ap-
proximately 2 seconds to access
machine configuration menus. Use
Menu button to cycle through para-
meters that can be set.
2 Parameter Display
3 Setting Display
4 Encoder
Rotate Encoder to adjust
parameter setting.
. To exit menu, press and hold
Menu button until Menu Off is
displayed.
1
ONOUT
MENU
23
4
[HOTS OFF]
No additional starting amperage to assist in starting
the electrode.
Trigger Mode Selection:
[RMT] [STD]
Typically used with a remote foot or hand control.
RMT STD requires a maintained contact closure to
enable weld output. Amperage can be controlled
with a remote potentiometer, or it can be set at the
control panel.
[OUT] [ON]
! Weld output terminals are energized at all
times when displays read [OUT] [ON].
No remote control or trigger required. Amperage
can be controlled at the control panel or with a
remote potentiometer. Blue output on LED illu-
minates to indicate output is on.
Arc Starting Method Selection:
[HOTS] [ON]
Provides additional amperage while striking the
electrode to prevent the electrode from sticking.
ON
USER
HOTS
Or
247222-D
To Next Page
