SECTION 2 – INSTALLATION
2-1. Specifications
Rated Output
Max. Open
Rated Input
Amperage at
Rated Output
Model
100% 60% 35% 20%
Circuit
Voltage
230 V 400 V
Dimension (mm) Weight (kg)
183
80 A
18 V
110 A
19 V
- -
180 A
23 V
32
16 A
1.5 A*
9 A
0.90 A*
310 x 540 x 957 57
243
145 A
21 V
190 A
23 V
240 A
26 V
- - 38
23 A
2.4 A*
13 A
1.38 A*
310 x 540 x 957 76
323
190 A
23.5 V
250 A
26.5 V
300 A
29 V
- - 49
41 A
3 A*
24 A
1.75 A*
310 x 540 x 957 102
Wire feed speed range 1.8 mpm to 18 mpm.
* While idling
2-2. Duty Cycle and Overheating
4 Minutes Welding 6 Minutes Resting
6 Minutes Welding 4 Minutes Resting
Duty Cycle is percentage of 10 min-
utes that unit can weld at rated load
without overheating.
If unit overheats, thermostat(s)
opens, output stops, and cooling
fan runs. Wait fifteen minutes for
unit to cool. Reduce amperage or
voltage, or duty cycle before
welding.
Y Exceeding duty cycle can
damage unit and void
warranty.
Overheating
0
15
A or V
OR
Reduce Duty Cycle
Minutes
duty1 4/95 – SB-150 215
40% Duty Cycle at 250 Amperes
60% Duty Cycle at 200 Amperes
WELDING AMPERES
% DUTY CYCLE
300
250
200
150
100
90
80
20 30 40 50 60 70 80 90 100
183
243
323
