TM-716 Page 25MSW And LMSW Series
Description
Part
No.
Dia.
Mkgs.
Item
No.
Figure 9-1. Main Assembly (Continued)
Quantity
Model
41,41T 42,42T 52,52T
15 010 716 CLAMP, connecting top tong braid 1 1 1... ............. .. ................... .... ....
16 602 008 SCREW, .250-20 x 1.000soc hexhd (Prior to LC622590) 4 4 4... ............. .. .... ....
16 602 008 SCREW, .250-20 x 1.000soc hexhd (Eff w/LC622590) 2 0 2... ............. .. .. .... ....
17 602 262 HANDLE, wood 1 1 1... ............. .. ................................... .... ....
18 024 130 BRACKET, mtg handle 2... ............. .. .............................
19 601 778 BOLT, crg stl .250-20 x 4.500 1 1 1... ............. .. ....................... .... ....
20 601 854 NUT, al hex .375-24 2 2 2... ............. .. ............................... .... ....
21 010 710 STUD, stl .375-24 x 3.375 (Prior to JE29) 1 1 1... ............. .. ............. .... ....
21 095 297 STUD, stl .375-24 x 3.750 (Eff w/JE29) 1 1 1... ............. .. ............... .... ....
22 026 607 GUARD, spatter 1 1 1... ............. .. ................................... .... ....
24 070 017 INSULATION, switch 1 1 1... ............. .. .............................. .... ....
25 S1 *011 746 SWITCH, control (includes) 1 1 1... .... ..... .. ......................... .... ....
011 291 CONTACT, assembly switch 1 1 1.................... .... ...................... .... ....
023 987 CONTACT, switch 1 1 1................... .... ............................... .... ....
011 292 TOGGLE, switch 1 1 1.................... .... ................................ .... ....
070 035 BASE 1 1 1................... .... .......................................... .... ....
26 122 210 SCREW, 10-32 x .625hexwhd slt stl 2 2 2... ............. .. .................. .... ....
27 026 759 INSULATOR, plug sec scr 2 2 2... ............. .. .......................... .... ....
28 010 711 PIN, spring .375-3.00 1 1 1... .............. .. .............................. .... ....
29 017 667 HOUSING, front (Prior to KE664390) 1 1 1... ............. .. ................ .... ....
29 169 122 HOUSING, front (Eff w/KE664390) 1 1 1... ............. .. .................. .... ....
30 NAMEPLATE (order by model and style number) 1 1 1... ........................ ...... .... ....
31 602 024 SCREW, drive U 2 x 3/16 4 4 4... ............. .. ........................... .... ....
32 010 708 RETAINER, clamp tong 1 1 1... ............. .. ............................ .... ....
33 026 605 INSULATION, bottom clamp 1 1 1... ............. .. ........................ .... ....
34 181 179 INSULATION, tong 1 1 1... ............. .. ................................ .... ....
35 602 004 SCREW, cap stl sch .250-20 x .750 2 2 2... ............. .. .................. .... ....
36 010 707 CLAMP, bottom tong 1 1 1... ............. .. ............................... .... ....
37 039 052 CLAMP, threaded connecting tong braid... ............. ..
(included w/Item 5, Fig 6-2) 1 1 1......................... .... ....
38 T1 +036 825 TRANSFORMER, pwr main (Prior to JE35) (Fig 9-2) 1... .... .... .. ...
38 T1 +095 345 TRANSFORMER, pwr main (Eff w/JE35) (Fig 9-2) 1... .... .... .. .....
38 T1 +036 950 TRANSFORMER, pwr main (Prior to JE35) (Fig 9-2) 1... .... .... .. ..........
38 T1 +095 350 TRANSFORMER, pwr main (Eff w/JE35) (Fig 9-2) 1... .... .... .. ............
38 T1 +036 826 TRANSFORMER, pwr main (Prior to JE35) (Fig 9-2) 1... .... .... .. .................
38 T1 +095 354 TRANSFORMER, pwr main (Eff w/JE35) (Fig 9-2) 1... .... .... .. ...................
143 140 LABEL, warning general precautionary 1 1 1................... .. ............... .... ....
39 600 675 SPLICE, butt 16-14 wire 2 2 2... ............. .. ............................ .... ....
40 111 630 SCREW, 10-32 x .250hexwhd slt stl 1 1 1... .............. .. .................. .... ....
41 019 642 COVER 1 1 1... ............. .. .......................................... .... ....
42 601 847 NUT, stl slflkg hex mscr 10-32 4 4 4... ............. .. ....................... .... ....
43 115 104 CONNECTOR, clamp cable 1/2 in (Prior to LB015364) 1... .............. .. .
43 134 900 STRAIN RELIEF, cable flexible (Eff w/LB015364) 1... ............. .. ......
43 115 104 CONNECTOR, clamp cable 1/2 in (Prior to LB022769) 1 1... .............. .. ........ ....
43 134 900 STRAIN RELIEF, cable flexible (Eff w/LB022769) 1 1... ............. .. ............. ....
44 094 503 CABLE, pwr 10ft 16ga 3/C 1... ............. .. ..........................
44 094 504 CABLE, pwr 10ft 16ga 3/C 1 1... ............. .. ................................. ....
45 026 763 TUBING, gl acrylic No. 7 x 2.500 3 3 3... ............. .. .................... .... ....
46 128 237 SCREW, 10-32 x .500hexwhd slt stl 4 4 4... ............. .. .................. .... ....
47 602 205 WASHER, tooth .195 id x 0.381 od x .025t stl pld int #10... ............. ..
(Eff w/LC622590) 1 0 1.................................. .... ....
48 217 299 SCREW, .250-20 x .87 soc hex gr8 pln (Eff w/LC622590) 2 0 2... ............. .. .... ....
49 110 463 TUBING, corrugated plastic slit .250 dia... .............. ..
(Eff w/MA500121K) 1 1............................... ...........
*Recommended Spare Parts.
+When ordering a component originally displaying a precautionary label, the label should also be ordered.
To maintain the factory original performance of your equipment, use only Manufacturer’s Suggested
Replacement Parts. Model and style number required when ordering parts from your local distributor.
