OM-243 762 Page 11
SECTION 3 INSTALLATION
3-1. Specifications
Wire Diameter Range
Approximate
Wire Feed
Range
Cooling
Method
Maximum Spool
Size
Weld Circuit
Rating
Overall
Dimensions
Weight
.030 Thru .035 in.
(0.8 Thru 0.9 mm)
Aluminum Wire
.023 Thru 035 in.
(0.8 Thru 0.9 mm)
Hard Or Cored Wire
50 To 800 ipm
(1.3 To 20.3
mpm)
Air Cooled
4 in. (102 mm)
Diameter
100 Volts, 160
Amperes, 60%
Duty Cycle
Using Argon
Shielding Gas
Length:
15-1/4 in. (387 mm)
Width:
2-1/2 in. (64 mm)
Height:
9 in. (229 mm)
11.0 lb (5.0 kg)
Gun With Cable
. Use welding power source Owner’s Manual during gun installation. If contact tip, liner, and drive roll groove are not correct for wire size and type,
see Section 5 to change parts as needed. See Parts List for other available contact tips.
Notes
16 Gauge (.063 in.)
22 Gauge (.031 in.)
24 Gauge (.025 in.)
20 Gauge (.037 in.)
18 Gauge (.050 in.)
14 Gauge (.078 in.)
1/8 in. (.125 in.)
3/16 in. (.188 in.)
1/4 in. (.25 in.)
5/16 in. (.313 in.)
3/8 in. (.375 in.)
1/2 in. (.5 in.)
MATERIAL THICKNESS REFERENCE CHART
