OM-169 510 Page 18
RAT I NG OF POWER SOURCE
$WTBD3 1
TYPE SEPA . SYNER. T IG
RAT I NG CURRENT 30 0A
W–FEEDER RAT I NG 256 i .
PUSH RECORD AFTER SETT I NG
AX I S ML4
TEACH
SERVO OFF
12. Press the RECORD
RECORD
key.
AX I S ML4
TEACH
SERVO OFF
DISP. REF. DISP. REF.
1.50A1.5V50i. 2.0V
2.150A 4.5V 102 i . 4.0V
3.200A 6.0V 153 i . 6.0V
4.250A 7.5V 205 i . 8.0V
5.300A 10.0V 256 i . 10.0V
13. Use the INCREMENT
+
or DECREMENT
_
key and forward or back DISPLAY SE-
LECT key to change the scaling of the amperage and reference voltage.
AX I S ML4
TEACH
SERVO OFF
DISP. REF. DISP. REF.
1. 5A 0.0V 50i . 2.0V
2. 79A 2.0V 102 i . 4.0V
3.190A 5.0V 153 i . 6.0V
4.301A 8.0V 205 i . 8.0V
5.375A 10.0V 256 i . 10.0V
