OM-169 510 Page 19
14. Press the RECORD
RECORD
key.
TEACH MODE
SERVO OFF
SENSOR AR
SELECT TYPE OF PARAMETER
BY FUNCT ION KEY
C–S TOUCH–S W–CHARA S–DATA >
15. Check settings of weld characteristics as follows:
a. Press the F4
F4
key to select the W–CHARA function.
POWER SOURCE WI RE
GMAW .035 .045 .062
SYNERGIC .035 .045 .062
GTAW–100 .035 .045 .062
GTAW–300 .035 .045 .062
USER REGI STER
DI F Y SC _ E D I T
AX I S ML4
TEACH
SERVO OFF
REG I ST MO
b. Press the F2
F2
key to select the MODIFY function.
RAT I NG OF POWER SOURCE
$WTBD3 1
TYPE SEPA . SYNER. T IG
RAT I NG CURRENT 30 0A
W–FEEDER RAT I NG 256 i .
PUSH RECORD AFTER SETT I NG
AX I S ML4
TEACH
SERVO OFF
c. Press the RECORD
RECORD
key.
