7ML19981CJ01 MiniRanger Plus Page 17
Installation
Terminal Block Layout (Panel Mount)
Warning:
All field wiring must have insulation suitable for at least 250V.
Hazardous voltage present on transducer terminals during
operation.
RS-232 ground onl
y
