7ML19981CJ01 MiniRanger Plus Page 63
Parameter Description
P610 Head Breakpoints
The head breakpoints for which flowrate is known.
These are the values in the Span for which flowrates are known. See Open
Channel Monitoring (OCM) on page 53 for a description of how to specify
breakpoints.
Values
0.0 to 15.0 meters (or equivalent units as defined by P005)
P611 Breakpoint Flowrates
The flowrate corresponding to each Head Breakpoint entered.
These are the flowrates for the related breakpoints. . See Open Channel
Monitoring (OCM) on page 53 for a description of how to specify
breakpoints.
Values
0.000 to 30,000
P640 Remote Totalizer Multiplier
Multiplies the number of OCM units needed per relay “click.”
Enter the factor (powers of 10 only) by which actual volume is divided, prior
to Remote Totalizer count increment.
e.g. for a Remote Totalizer update by 1000's of volume units, enter 3.
Note:
When the MiniRanger is put into program mode the cumulative total used
to trigger the next totalizer relay “click” is reset to 0. This disruption will
cause the external totalizer to read lower than the actual OCM total,
depending on the number of times programming mode is used and the
amount of time spent there.
Values
0 = 1
1 = 10
2 = 100 (default)
3 = 1000
4 = 10,000
5 = 100,000
6 = 1,000,000
