Page 62 MiniRanger Plus 7ML19981CJ01
Parameter Description
P600 Primary Measuring Device
The type of primary measuring device (PMD) used for Open Channel
Monitoring (OCM).
Note:
OCM calculation is an optional feature. MiniRangers with the OCM feature
have this icon on the front: .
P600 must be set to “1” for Flow function which allows access to flow
parameters. After performing a Master Reset (P999) P600 defaults to "0" (no
OCM calculation).
Values
0 = off (no OCM calculation) (default)
1 = Universal Linear Flow Calculation (see P610, P611)
Note:
When P600=1, then P112 Relay A Setpoint and P113 Relay B Setpoint
are not applicable.
P604 Maximum Flow
The maximum flowrate associated with the top of Span (P007).
This value represents the flow at the highest head level supported by the
PMD. It works in conjunction with Span (P007) to define the highest point in
the curve.
Use this parameter with Time Units (P606) to define the flowrate units.
Values
0 to 30,000
Preset = 100
P606 Time Units
Defines the time element of the flow units.
e.g. If flowrate is displayed in millions of gallons / day, and the maximum
flowrate is 376,500,000 gallons / day, enter “376.5” for Maximum Flow
(P604) and “4” for Time Units (P606).
Values
1 = seconds
2 = minutes
3 = hours
4 = days (default)
