7ML19981CJ01 MiniRanger Plus Page 61
Parameter Description
P111 Relay Function
Assigns an alarm function to the selected relay. Refer to page 36.
entry :
0 = off (default)
1 = alarm on level
2 = control
3 = control with pump sequencing (both relays must be set to 3)
4 = alarm on loss of echo
Note:
OCM calculation is an optional feature. MiniRangers with the OCM feature
have this icon on the front: .
P112 Relay A Setpoint
The on setpoint in linear units (P005). Refer to page 36.
P113 Relay B Setpoint
The off setpoint in linear units (P005). Refer to page 36.
P200 mA Range
Enables the mA output function by selecting the range and relationship to
span. Refer to mA output on page 40.
entry :
1 = 0 to 20 mA
2 = 4 to 20 mA
3 = 20 to 0 mA
4 = 20 to 4 mA
P300 Temperature, Transducer Max
The maximum temperature encountered by the integral (transducer)
temperature sensor.
P341 Run Time
View the accumulated number of days the MiniRanger Plus has been
operating.
