P-51 OCM simulation
press , display will show previous flow
enter head in units programmed, display will show head
press , display will show corresponding flow
Parameters P-52 through P-59 are used specifically for OCM
and pump totalizer applications. Refer to Applications.
P-52 totalizer display factor
totalizer display of flow or volume pumped is factored by a power of
10 to determine the count per flow. The factor is selected as follows:
enter: – 3 =multiply by 1000
– 2 =100
– 1 =10
0 =divide by 1 ( F )
1=10
2 =100
3 =1,000
4 =10,000
5 =100,000
6 =1,000,000
7 =10,000,000
e.g. present flow rate is 450 gal / sec
if P-52 = 0, totalizer is incremented at a rate of 1 count per gallon
if P-52 = 3, totalizer is incremented at a rate of 1 count
per thousand gallons
P-53 totalizer decimal point location
sets the number of digits after the decimal point for the low total
only. The decimal point will not float.
enter: 0 = no digit after decimal
1 = one digit after decimal
2 = two digits after decimal ( F )
3 = three digits after decimal
P-54 low total
this parameter will display the 4 lowest digits of the 8 digit totalizer
used in pump totalizer or OCM application. The parameter will also
allow the display to be reset to any value. ( F = 00.00 )
94/09/20
ENTER
ALT
DISP
PL-443 7 – 13
