9
Operation modes
The device operates under three different operation modes as shown below.
Not-ready mode
When the power is turned on, the device enters the not-ready mode and stays there until a sheet of media is detected. The keys other than the
REMOTE
,
FEED
and
SHEET SET
keys are effective.
Example of display
The function to enable operations of the jog keys or plotter is not effective. (Such as in the case of executing test cutting or sample cutting)
If you executed any of the aforementioned disabled function, the following message will appear on the LCD.
Local mode
The device enters the local mode after the sheet detection.
Normally, tool conditions appear on the display panel. Under the local mode, all keys are effective to enable setups.
The device is able to receive data sent from the host computer, however, it will not perform cutting (plotting).
Example of display
Remote mode
The device performs cutting under this mode.
The
REMOTE
key and
REMOTE
keys are effective.
If you press the
REMOTE
key during cutting , the device will be put on hold. Another press on the same key will allow the device to resume
cutting.
If you press the
ENTER
key while the device is put on hold, the hold function that corrects the sheet that has slipped out of position.
Example of display
ERR30 OPERATION
ROLL <R> LEAF
**NO SHEET**
CUT1 20 040 0.30
CUT1 ** REMOTE **
The power is
turned on.
Sheet detection
Not ready
mode
Local mode
Remote mode
key
key
SHEET SET
REMOTE
