3. Consumable Item Replacement
27
5
Mount the sliders on to the new media holder.
• Engage the holes in the sliders on to the lugs on the media holder.
6
Mount the new media holder on to the platen.
7
Secure the media holder stopper with the screw.
8
Close the maintenance covers.
Media Cutter Replacement
Replace cutters when blades are chipped or blunt.
• Avoid touching the cutter blade. Failure to do so may result in injury.
1
On the LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.
2
Select [Station] > [Carriage Out] > [Move To Platen Right End], then press the [ENTER] key.
• The carriage moves over the platen.
To Next Page
