A-2 Accutorr 3 Operator's Manual
A.3 Power Supply Specifications
AC Power
Line voltage
100 to 240 VAC ~ (±10%)
Current 0.9 to 0.5A
Frequency
50/60 Hz (±3Hz)
Fuse T2AL-250V
Battery
Battery Type
Rechargeable lithium-ion, LI23S002A
Voltage 11.1 VDC
Capacity 4500 mAh
Run time
At least 22 hours when powered by a new fully-charged
battery at 25°C±5°C (77°F±9°F) with SpO
2
cable connected, and
auto NIBP measurements at an interval of 15 minutes.
Charge time
Monitor power off: less than 5.5 hours to 90%; less than 6.5
hours to 100%.
Monitor power on: less than 10.5 hours to 90%; less than 11.5
hours to 100%.
Shutdown delay At least 20 minutes (after a low battery prompt first occurs)
A.4 Physical Specifications
Size 134mm × 120mm × 243mm
Weight ≤1.9 kg (with SpO
2
module, NIBP module and a battery)
≤1.7 kg (with NIBP module and a battery)
A.5 Hardware Specifications
A.5.1 Display
Screen type Segment display
Screen Size 90mm × 99mm
