BeneVision N17/BeneVision N15/BeneVision N12 Patient Monitor Service Manual 7-21
7.3.4.2 Parts List
ITEM No. Description Qty FRU Part No.
1 N15N17 module rack assembly (with SMR/BNC) 1 /
2
Small cross recessed pan head GB9074.5-88 M3X6
with pad and plated with green color zinc
/ /
3
N17 main bracket asembly (iView or independent
display)
1 /
4 Conductive foam 3.2*6.4mm / /
5 Speaker bracket 1
115-044547-00
6 Speaker 2W 40hm 1
7 MK speaker foam 1
8 Cross recessed pan head thread-cutting tapping
screws PT3X8 plated with green color zinc
/ /
9 TR6F recorder 1 /
10 AC inlet hook 1 9211-20-87369
11 N17 rear housing (silk screen) 1 043-007458-01
12 Waterproof foam (N17) 1 048-006292-00
13 Handle right damping block, N17 1 /
14 Blind rivet hole BSO-3.5M3-35 ZC / /
15 Handle left damping block, N17 1 /
16 N17 top cover 1 043-007661-01
17 Cushion pad 2 115-044549-00
18 N17 handle 1
