6-24 BeneVision N17/BeneVision N15/BeneVision N12 Patient Monitor Service Manual
6.6 Further Disassembly of the Base Assembly
 N12
Remove the battery door connecting belt from the through hole, and remove the battery door.
 N15/N17
1. Loosen and remove the two M3X6 screws, and remove the battery interface board.
2. As shown below, open the battery door, insert a pad between the battery door and the base and
press down firmly to remove the battery door.
