7-28 BeneVision N17/BeneVision N15/BeneVision N12 Patient Monitor Service Manual
7.5 M51C Module
7.5.1 Exploded View
7.5.2 Parts List
ITEM No. Name and Specification Qty Material Code
1 M51C-ME, 5L5P, MR/NC-SPO2, IBP, MPM I/F 1 051-002482-00
2
Stainless steel cross recessed pan head screw
GB/T818-2000 M2X4
4 /
3 M51C-9008V3.0 SPO2 PCBA 1 051-002353-00
4 Hex nut and taper lock washer assembly M3 2 M04-011002---
5 M51C module back plane (with IBP/FRU) 1 051-002383-00-00
6 Fixing base 2 /
7
Cross recessed countersunk head screw
GB/T819.1-2000 M3X6
2 /
8 Spanner (T8) 2 /
9 Dual module rear housing (M51C) 1 /
10 Terminal screw 2 /
11 Infrared lens 1 /
12 Standard spring washer GB/T93-1987 3 2 /
