Controls and Indicators General Product Description
1 - 8 0070-10-0603-01 Duo™ Operating Instructions
1.2.3 Bottom Panel
The battery compartment and the mounting nut for the optional rolling stand are located on
the bottom panel as shown in FIGURE 1-7.
FIGURE 1-7 Bottom Panel
a. Mounting Nut
• The mounting nut secures the Duo to the optional rolling stand.
b. Battery Compartment
• The battery compartment houses one user-replaceable, rechargeable Lithium Ion
battery. For ease of use, the door for the battery compartment is tethered to the
bottom panel and features a molded finger grip.
