Operator’s Manual 14 - 1
14 Patient Data Management
An exam record consists of all information and data of one exam.
An exam record consists of the following information:
• Patient basic information and exam data
• Image files
•Report
• DO NOT use the internal hard drive for long-term image storage. Daily backup is
recommended. External storage media is recommended for archiving images.
• The system patient database space is limited, please back up or clear patient data in time.
• Mindray is not responsible for lost data if you DO NOT follow suggested backup procedures.
14.1 Image File Management
You can store the image files either in the patient database in the system, or to external memory
devices.For a save image, you can perform operations like image reviewing, analyzing and
demonstration.
14.1.1 Storage Media
System supported memory media including:
• System hard disk
• USB memory devices: USB flash drive, removable USB hard disk
• Optical disk.
14.1.2 Image File Formats
The system supports file formats which belong to the system and file formats which are PC-
compatible.
System-relevant formats
• Single-frame image file (FRM)
Refers to single-frame static image files not to be compressed; you can perform measurements
and comments adding on this type of files.
• Cine file (CIN)
System-defined multi-frame file format; you can perform manual or auto cine review, and
perform measurements or add comments for the reviewed images. After you open a stored CIN
file, the system automatically enters cine review status.
PC-compatible formats
• Screen file (BMP)
