A Barcode Reader

Operator’s Manual A - 9

Volume setting

Scan the following barcode to set the volume parameter.

•Low Volume

• Medium Volume

• High Volume

Code 93 and codabar setting

• To enable Code 93, scan the appropriate barcode below.

• To enable Codabar, scan the appropriate barcode below

Code 39 full ASCII setting

Code 39 Full ASCII is a variant of Code 39 which pairs characters to encode the full ASCII

character set. To enable or disable Code 39 Full ASCII, scan the appropriate barcode below.

Default Chapter3
- Responsibility on the Manufacturer Party3
- Warranty4
1 Safety Precautions17
- Meaning of Safety Symbols17
- Safety Precautions18
- Latex Alert23
