4 Setup
Operator’s Manual 4 - 33
TIP:
Not all SCPs can support verification. See the SCP properties to confirm whether the SCP can
support this service. If not, the verification will not be successful.
Perform the following procedure:
1. Click [Set DICOM Service] on the DICOM/HL7 screen.
2. Select the DICOM service tab to enter the corresponding settings screen.
3. Enter the correct AE Title, port, etc.
– Click [Add] to add the service to the Service List.
– Select an item in the service list, change the parameters in the above area, and click
[Update] to update the item in the service list.
– Click to delete the selected service in the service list.
– Select an item in the service list, click [Default] and you can see “Y” in the Default
column.
4. Click [Verify] to verify that the two DICOM application entities are properly connected.
If the verification is successful, the system displays “xxx Verify Succeed.” Otherwise, it
displays “xxx Verify Failed.”
If verification failed, possible causes may be: wrong IP address; not able to access IP address;
remote DICOM server is not running; wrong port; incorrect application name.
Storage Service Preset
DICOM storage preset items are described as follows:
Item Description
Device After you set the server (s) in DICOM Preset screen, the name (s) will
appear in the drop-down list, select the name of the storage server.
Service Name Default is xxx-Storage, user-changeable.
AE Title Application Entity title, here, it should be consistent with that of the storage
server.
Port DICOM communication port, 104 is default. Here, the port should be
consistent with that of the storage server port.
Maximum Retries Set the maximum retries (0-9). The default value is 3. If the DICOM task
sending to the server fails, the retry times should be 3.
Interval Time(s) Interval time.
Timeout Refers to the amount of time after which the system will stop trying to
establish a connection to the service.
TLS Transport Layer Security. Select whether to encrypt the data during network
transportation.
Cine Zoom Mode Select the cine zoom mode during image file storage.
Compression Mode Select the compression mode: original data (uncompressed), RLE (the
image not compressed), JPEG, and JPEG2000.
Compression Ratio Select the JPEG compression ratio: lossless, low, medium, and high.
The compression ratio is inversely proportional to the image quality
(reserved function).
