16 - 8 Operator’s Manual
16 Probes and Biopsy
A legally marketed probe sheath must be installed over the probe before performing intra-cavitary
and intra-operative examination. Protective barriers may be required to minimize disease
transmission. Probe sheaths are available for use with all clinical situations where infection is a
concern.
To order probe sheath, contact:
CIVCO Medical Instruments Co.
102 First Street South, Kalona, IA 52247-9589 USA
Tel: 1-319-656-4447
E-mail: info@civco.com
http://www.civco.com
Refer to the following dimension table of all probes to choose the necessary probe sheath type. You
can select the probe sheath according to the actual application situation.
The following figure is a dimension illustration of the V11-3s probe.
Probe Mode Length(mm) Width(mm) Height(mm) Cable Length(mm)
C5-1s 76.7 109.6 28 2050±50
SC5-1Ns 111.8 76.7 28 2050±50
V11-3s 317 41 33 2050±50
V11-3Hs 319.6 33 38.1 2050±50
L11-3VNs 43.3 10.4 12.6 2050±50
L12-3RCs 101.8 55.6 22 2050±50
L13-3s 101.6 61 25.7 2050±50
L13-3Ns 101.1 56.8 22 2050±50
L14-6Ns 101.6 61 25.7 2050±50
L20-5s 98 43 22.8 2260±50
P4-2s 102.7 38.1 27.8 2050±50
SP5-1Ns 102 38 30 2050±50
