Mindray Resona 7T Service Manual

Adjustments 7-1
7 Adjustments
7.1 Adjusting Monitor
7.1.1 Adjusting Position
7.1.1.1 Lifting support arm
 Height adjustment
Move the monitor support arm up or down to adjust the height.
NOTE:
Take care not to trap your hands when adjusting the monitor up and down.
 Rotate the monitor
 Upper arm rotation
The monitor can be rotated ±90° along with the supporting arm, or the supporting arm can be
fixed and the monitor can be rotated ±90° alone.

Lower arm rotation
Turn the locking lever at position, and then you can move the supporting arm
leftwards/rightwards.
