Mindray Resona 7T Service Manual

Field Replaceable Unit 8-31
No.
Order Number
Part Name
Qty.
Remark
H30 009-005338-00 power output wires 12V TDK 1 ACDC Module-ACDC connection board
H31 009-005339-00 AC-DC power output control wires TDK 1 ACDC Module-ACDC connection board
H32
009-004578-00
AC_DC POWER input WIRES
1
AC connection board,J1-ACDC Module
H33
009-004579-00
power output connecting wires(24V)
1
ACDC Module-ACDC connection board,J12/J10
H34
009-004581-00
cable of breaker to connecting board
1
circuit break – AC connection board,J9
H35 009-004582-00 auxiliary output control signal cable 1
AC connection board,J7-ACDC connection
board,J19
H36 009-004583-00 12V power output wires 1
Mother board,J57-base power box, ACDC
connection board
H37 009-004584-00 AC-DC POWER control WIRES 1
Mother board,J61-base power box, ACDC
connection board
H38 009-004585-00 AC-DC24V POWER OUTPUT WIRES 1 ACDC connection board-lift control board,J3
