3-30 System Installation

NOTE:

When the system background is processing network task (DICOM sending for example),

please do not enter network setting to change the IP or Eap, otherwise the background

task may fail. You can check if there are tasks undergoing in the task manager.

 IP Config

IP config is used for setting local network parameters, which is also applied to DICOM connection.

1. In Wireless network manager screen, click [IP Config] to open the page:



If “DHCP” is selected, the IP address will be automatically obtained from the DNS server.

 Click [Refresh] to check current IP address.

 If “Static” is selected (using a static IP address), enter the IP address.

 IP address of the system should be in the same network segment with the server.

 Subnet Mask: set different network segment.

 Gateway: set the gateway I P.

NOTE: the name of the device is saved under the service name by default. The system

remembers the service name of the ultrasound system when sending the image, the

report to DICOM server. Open the file (DCM Editor Tool、eZDicom.exe) to view the

service name (iStation Name).

2. Click [Apply] to save current setting. Click [Close] to exit.

NOTE:

If the IP address displays as 0.0.0.0, this means that the network is abnormal. The

reason for the failure may be disconnection or the system cannot obtain the IP address.
