System Overview 2-9
No. Name Function
1. Monitor
Displays the images and parameters during scanning.
2. Touch Screen Screen-touching operator-system interface or control.
3. Ultrasound gel warmer Used for heating the ultrasound gel.
4.
ultrasound gel holder
Used for placing transducers or ultrasound gel temporarily.
5. Control panel Key- pressing operator-system interface or control.
6. Qwerty keyboard Used for typing characters or entering some functions.
To Next Page
