Image Optimization 5-1
5 Image Optimization
WARNING:
1.
The images displayed in this system are only
reference for diagnosis. Mindray is not responsible
for the correctness of diagnostic results.
2.
In Dual-B imaging mode, the measurement results of
the merged image may be inaccurate. Therefore, the
results are provided for reference only, not for
confirming a diagnosis.
5.1 Imaging Mode
5.1.1 Switching Between Image Modes
Refer to Chapter 2.9 Control Panel for image mode switch.
Quickly switch imaging mode
Press the <Menu> key on the small key board to quickly switch to the special mode. The available
special modes are displayed on the top left corner of the screen. Press the <Menu> key again to close
the special menu.
5.1.2 Image Adjustment
Touch screen:
Touch screen displays:
1. Mode displaying area (or main functional tabs): displays the current modes, click the tab to enter
the mode.
2. Other application mode entrance: displays the available application modes related, click to enter
the modes.
3
1
2
