Barcode Reader A-1
Appendix A Barcode Reader
The product supports two kinds of readers for logging data as patient ID: 1-D barcode
reader (SYMBOL LS2208) and 2-D barcode reader (SYMBOL DS4308).
The laser transmitted by SYMBOL LS2208 is Class 2 laser.
SYMBOL DS4308 is classified as “EXEMPT RISK GROUP” according to IEC 62471:
2006 and EN 62471: 2008.
WARNING:
Class 2 laser adopts low power, visible LED. DO NOT stare
into beam because of unknown hazards of transient
radiation provided by class 2 laser.
DO NOT stare into beam emitted by SYMBOL DS4308 for
more than 10s.
CAUTION:
Ensure the information acquired by barcode reader is
consistent with the actual information.
NOTE: the reader does not support decoding of Multilanguage.
A.1 1-D Barcode Reader
There are 2 operation modes for 1-D barcode readers:
Hand-held mode: press the trigger to decode.
Hands-free mode: seat the reader in the stand to enter the mode, the reader decodes
automatically.
A.1.1 Overview
Green: A barcode was successfully decoded.
Red: A data transmission error or reader malfunction occurred.
2. Scan window Scan the barcode.
