Control
Description/Use
One-up / 4-up Toggle
Softkey Label:
See the pre-acquisition softkeys.
Slice Selection
Softkey Label:
Press to select a slice or volume: A / B / C / V
Default slice is A
Cubic Dimension
(6 sides)
Softkey Label:
Press to select the viewing side for the active slice or volume
Default is Top view
When Light is selected, the following softkey is displayed:
Softkey Label:
Toggle up or down to select the light direction for the active volume.
Default is front view.
Trackball will also control direction of light while this softkey is active.
lume Rotation
Softkey Label:
Press to rotate the volume to one of 4 discrete degrees:
0 / 90 / 180 / 270
Default is 270 degrees.
Volume Movement
Softkey Label:
Turn to move through the volume set: XYZ
Rotation
(3 axes plus rotation)
Default Softkey:
Turn to rotate the selected plane or volume
Press to switch the axes. Default is Volume with Z-axis
Softkey options:
X-axis Y-axis Z-axis
Can alternatively use these Major Mode buttons on the Control
Panel:
M = X-axis / D = Y-axis / C = Z-axis
