Control Panel
The ZS3 has a full –featured control panel/ user interface (see Quick Start Guide below).
Multi-Transducer Port
The multi-transducer port (MTP) allows up to three imaging transducers simultaneously
connect to the system. You can easily activate any of the transducers connected to the cart.
Transducer Holders
The Safe storage for transducers is provided on both sides of the ZS3 System (Figure 2.1).
Internal Cart Solid State Drive (SSD)
All exam images are initially archived to the Cart SSD.
This data can be then be transferred to PACS, USB drives, networked or thermal printers,
and FTP destinations. It can also be backed up and restored on other ZS3 systems.
See Chapter 7. Archiving, Review and Management for more details.
The standard size of the SSD is 128 GB.
NOTE: The internal hard drive is not intended for use as a long-term archive. Back up of
exam data is recommended regularly.
USB Ports
Four USB ports (two in the front and two in the back) allow importing/ exporting of exams
to/from the system as well as to install software and to backup/restore system and preset
preferences.
Note: Before deleting any exam data from the cart hard drive, always verify that data was
successfully transferred to the USB device by viewing it on an external computer.
When exams are exported onto the USB device, a DICOM viewer program (Showcase
®
) and its
user’s manual are simultaneously exported onto the USB, allowing the exams to be opened,
annotated, and saved in several formats on any commercial PC.
Barcode Reader (Option)
Patient accession numbers, ID, name, age, DOB, gender, Operator ID etc. can be entered via a
selection of Mindray-approved barcode readers that can connect to a system USB port (note:
capability and content is dependent on type of scanner used).
