CINE Control
Description/Use
Trim
Pressing this control allows user to trim a section of cine buffer or stored clips, to save as
separate clips
Cine Flush Pushing the dial flushes the CINE buffer resetting the frame counter to 0
Retro
On/Off
Toggle Retrospective Capture On and Off
Clip A/Peak Hold/
Toggle Clip A, Peak Hold, and Clip B which may have different Clip Type selected
Clip Type
Secs/Beats
Allow user to assign Clip Type as Beats or Seconds.
• Pushing the dial toggles between Beats and Seconds.
• Turning the Dial changing the number of beats or seconds.
• “Max” selection allows for open-ended clips. Clips are not
automatically terminated upon reaching beats or seconds, but rather
are manually terminated by pressing the Store or Print key a second
time while clip store is in progress.
Clip Pause/Resume Allows user to pause storing a clip.
• Press the button to toggle between Pause Clip Store and Resume
• Still frames can be stored during the pause
• Alternately, user can assign a Programmable key to Clip Pause/Resume
Capture Rate Allows user to manually set the Capture Rate. If the selected capture rate is
greater than the imaging frame rate, the capture rate is automatically set to the
Frame Rate.
• Turn the dial to select settings from 5Hz-MAX
• Turn the dial to select Actual to maximize number of frames
Stopwatch
Start/Stop
Toggles between Start and Stop for timers
• Pushing the button starts and stops an onscreen timer
Stopwatch
Phase/Reset
Toggles between Phase and Reset
• Once a timer has been started, pushing the button starts additional
phases (up to 4) of the timer.
• After pressing Stopwatch Stop, pressing the button resets all timers.
Full Image
On/Off
Toggle between Full Image and Standard Image Display
Hide Pt Bar Remove the Patient Identifiers from the screen
Image Data
On/Off
Toggle Image Parameters On/Off
Reset Cine Pressing “Reset Cine” Resets:
• The trim limits
• Cine Select Chapter and Frame to last in the buffer
• Playback speed to 100%.
